3 in 1 DisplayPort to HDMI VGA or DVI Adapter (3 in 1 DP to HDMI/VGA/DVI Converter) is perfect for home theater or desktop audio video applications. Connects a DisplayPort (DP, DP++, DisplayPort++) equipped laptop or desktop to an HDTV, Monitor, Projector, Flat Panel Display, Digital CRT Display or other device with HDMI, VGA or DVI input. Converts DisplayPort digital signal to HDMI digital signal, VGA analog signal or DVI digital signal. HDMI output supports video resolutions upto 4K@60Hz (3840x2160, Ultra HD), VGA and DVI outputs support video resolutions upto 1920x1200 or 1080P (1920x1080, Full HD). High quality materials and construction ensure a lifetime of dependable performance. Fully-shielded conductors provide complete immunity to EMI/RFI interference, and 24-K gold plated connectors ensure superior signal transfer. This fully-functional, high bandwidth cable is tested to perform at industry standards and is backed by Umateck 2 Years warranty.

Key Features

• High Quality 3 in 1 DisplayPort Male to HDMI/VGA/DVI Female Adapter (DP to HDMI/VGA/DVI Converter)
• Connect a DisplayPort (DP, DP++, DisplayPort++) equipped computer to an HDTV, Monitor or Projector with HDMI VGA or DVI input
• HDMI output supports a video resolution upto 4K*2K@60Hz
• VGA & DVI outputs support a video resolution upto 1920x1200 or 1080P@60Hz
• Connect and configure your monitor for an Extended Desktop or Mirrored Displays
• Feature a built-in IC chip to achieve better compatibility
• It is not a bi-directional adapter cable, can only convert signal from DisplayPort to HDMI VGA or DVI
• The adapter will output signal to one video port at a time, is not designed to output multiple video signals simultaneously
• DisplayPort connector with latches provides a secure connection with a release button that must be depressed before unplugging

Electrical Characteristics:
• Nominal Velocity of Propagation - 21.6Gbps
• DC Resistance - 300V
• Dielectric Strength - AC 500V/minute
• Insulation Resistance - 100Ω
• Time Delay - 5.2ns/m (max)
Physical Characteristics:
• Voltage Rating - 30V
• Maximum Bend Radius - 90mm
• Temperature Rating - 80℃
• Operating Temperature Range - -20℃- 80℃
• Storage Temperature Range - -25℃- 85℃
• Approvals – RoHS, CE, UL Compliant
Conductor 1 (5 Pairs)
• Conductor Type - 32AWG Tinned Copper
• Insulation - Foamed PE SKIN
• Drain Wire - 32AWG Tinned Copper
• Shield - Aluminum Foil, 100% Coverage

Conductor 3 (5 Conductors)
• Conductor Type - 32AWG Tinned Copper
• Insulation - HDPE
Overall Cable
• Drain Wire - 30AWG Bare Copper
• Foil Shield - Aluminum Foil, 100% Coverage
• Braided Shield - 16/5/0.12, Al/Mg
• Jacket - PVC, Black, O.D.: 4.8±0.2mm
Connector 1
• Connector Type – DisplayPort Male
• Pin Construction - Phosphor Copper
• Injection – ABS
• Plating – Gold
Connector 2
• Connector Type – HDMI Male + VGA Female + DVI-I 24+5 Female
• Pin Construction - Phosphor Copper
• Injection – ABS
• Plating – Gold
